Anatomy of a Typical IPF Orchestration Application

An IPF orchestration application consists of several key components that work together to process and route messages. This document outlines the architecture of an IPF orchestration application, covering the interactions between these components, the flow of messages, and how backpressure is handled.

Core Components

Diagram

Domain Components

The Domains component depicted in the diagram above encompasses DSL-defined and MPS-generated components that provide the orchestration logic within the IPF Orchestration Service:

  • Flow Event Sourced Behaviours (ESBs): These form the core of the orchestration logic, implementing finite state machines that drive business processes. ESBs are fully generated by MPS and use event sourcing, reading and persisting domain events via the Akka Persistence Plugin.

  • Input Adapters: These components send inputs to the flow ESBs, triggering transitions between finite state machine states. Input Adapters are fully generated by MPS.

  • Action Adapters: Defined by the IPF orchestration service, these components implement the Action Ports generated by MPS and integrate with the Domain via those interfaces. Action Adapters are implemented by the engineering team creating the orchestration service.

Connectivity Components

  • Receive Connectors: Components from IPF system connectivity libraries that consume messages sent by external domains. Their primary function in an orchestration service is to convert incoming messages into appropriate Input objects and forward them to the relevant Input Adapter.

  • Send Connectors: Similar to Receive Connectors, but designed for outbound communication. These components transmit messages to external domains.

  • Cache Adapters: Provided by IPF Cache libraries, these components typically operate in front of Request Reply Send Connectors to cache results of HTTP calls. They delegate to connectors when a cache miss occurs but return cached results when available.

System Interaction and Message Flow

IPF components interact in a coordinated manner to process messages. Understanding this flow and how backpressure is applied throughout the system is essential for troubleshooting, capacity planning, and performance optimization.

Message Flow Process

ipf message flow drawio

Below is a brief description of each step in the message flow. Note that, due to Akka cluster sharding, steps 1-3 and 4-7 are likely to be performed on different IPF orchestration service nodes.

  1. Messages usually enter an IPF orchestration service via a Receive Connector

  2. The connector transforms the received message into an appropriate Input and calls the relevant Domain Input Adapter

  3. The sole purpose of the adapter is to convert the input into a command and send it to the appropriate Flow ESB, which may reside on a different service node

  4. When it receives the command, the Flow ESB first checks whether the command should be applied. If the check passes, an event is persisted using the persistence plugin. If the check fails, further steps are skipped.

  5. (Optional) Akka Persistence Plugin converts the events into database write commands and communicates with the database

  6. (Optional) If there are configured actions (side effects) to be triggered upon event persistence, the Flow ESB triggers them at this point via the appropriate Action Adapter.

    • If the configured action implementation models an interaction with an external system, a Send Connector can be used to execute this, as shown in step 7. The choice of Send Connector is informed by the type of action that has been modelled:

      • A Request-Response action is used — A Send Connector or an uncached Request Reply Send Connector is used to send a message. Any potential response to that message from the external domain will be received via a Receive Connector.

      • A Domain Function action is used — A potentially cached Request Reply Send Connector is called, meaning a configured Cache Adapter is first inquired.

        • On a cache miss, the Request Reply Send Connector call proceeds and the result of the operation is stored in the cache for future use.

        • On a cache hit, we skip step 7.

    • If the configured action implementation represents a process that’s handled entirely within the boundaries of the domain, a Send Connector is not required and the Action Adapter converts the response into an appropriate Input and calls its Input Adapter, continuing the flow from step 3.

    • If no actions are to be triggered, step 7 is also skipped.

  7. (Optional) The connector converts the action’s data into a format that the external domain expects and sends it using the configured transport.

Backpressure

Backpressure is a means of flow-control and a way for consumers of data to notify a producer about their current availability, effectively slowing down the upstream producer to match their consumption speeds. Most reactive streams libraries offer developers several approaches (which can sometimes be combined) to use when backpressure is encountered:

  • Buffer messages

  • Slow down (throttle) the processing

  • Shed load (drop messages)

  • Take latest (head) message

Usually, backpressure applies within a single OS process (in our case, a JVM) and is most frequently mentioned in the context of reactive streams. Some messaging protocols do support backpressure as part of their specification, allowing signals to leave the confines of a single process (e.g., AMQP flow control).

Backpressure in Akka

IPF Connectors are built on top of Akka Streams, a reactive streams implementation, which comes with built-in backpressure mechanisms.

Akka actors communicate by asynchronous message passing, which by default offers no backpressure. However, backpressure can be added by applying the ask pattern, thus forcing users of any actors (which includes IPF flows) to wait for a response before proceeding further.

For flows, Akka Persistence will only allow a configurable number of flows to be initiated or rehydrated concurrently. This, in combination with the ask pattern mentioned above, acts as a protective barrier around the event store, propagating any backpressure from the database upwards.

Backpressure in DB

IPF uses the reactive streams MongoDB driver, which comes with built-in backpressure support. The MongoDB reactive client slows down on backpressure, and this backpressure is propagated to IPF Connectors and Akka Persistence.

Backpressure in Connectors

As mentioned before, IPF Connectors are built using Akka Streams, making backpressure a built-in feature.

All connector stages slow down consumption on backpressure by default, although certain stages do offer other options:

  • Source.queue is mainly used in Send Connectors to queue up messages for sending. It buffers requests to send up to a limit, then slows down producers up to a limit. Once both limits are breached, it starts to drop messages.

  • Flow.mapAsync is used in all types of connectors to perform various potentially long-running work — mapping, logging, correlation, appending to dead letter queues, etc. It can be seen as providing a buffer of concurrently executing requests, after which it slows down the upstream.

Backpressure in IPF (All Together)

ipf backpressure flow drawio

As explained in the message flow section, all IPF components are intricately linked together, causing their backpressure mechanisms to combine. In practice, Receive Connectors serve as the main bottleneck in the IPF orchestration service, where backpressure from downstream dependencies ultimately manifests. This means that the speed at which the Receive Connector consumes and processes work is determined by the processing speed of the entire message flow, and is no faster than its slowest step.

Backpressure flows through the service as follows:

  1. An External System creates a message and has it delivered via a transport of its choice. The chosen transport influences whether backpressure signals from the orchestration service reach the external system. HTTP can shed load by returning 503 errors on backpressure, AMQP supports slowing down producers, while Kafka and JMS simply act as buffers.

  2. Each Receive Connector will have one or more stages with a small buffer of messages that can be processed in parallel. When the buffer is full, the connector will backpressure and stop consuming new work. Messages are only removed from the buffer when their processing completes (successfully or not). Depending on the connector’s resiliency settings, processing of a failed message can be retried a configurable number of times until the max number of attempts is reached, or until the configured timeout duration elapses.

  3. An Input Adapter offers no backpressure mechanisms of its own and instead propagates downstream backpressure by awaiting confirmation — in the form of a successful processing outcome message — that steps 3-7 have completed successfully. The adapters come with their own RetrySupport — a (retryable) failed call to the Flow ESB will be retried a configurable number of times before the failure is propagated to the connector.

  4. Each call to the Flow ESB from an Input Adapter will use Akka’s support for location-transparent cluster messaging, and will wait for a configured amount of time for the processing outcome message to be received before timing out and signaling to the adapter’s RetryStrategy that the attempt has failed. Flow ESB actors process commands one by one and they buffer pending messages in their message queues. If the Flow ESB determines that the command should not be applied (e.g., it’s invalid for current state, a duplicate, etc.), a processing outcome is sent to the Input Adapter and further steps are skipped.

  5. The speed at which commands are processed directly depends on the speed at which the Akka Persistence Plugin can persist them. Once the event is persisted, the Flow ESB is free to accept new commands.

  6. All configured actions that the Flow ESB triggers are called asynchronously and in parallel. The processing outcome is sent to the Input Adapter from step 2 only after all actions have been completed.

  7. Depending on the action type and its implementation, different backpressure rules apply:

    • Decisions do not interact with external systems, but they do result in a chained execution that effectively triggers steps 3-7 and propagates their backpressure upstream to the Receive Connector.

    • Domain Functions may require external interactions, after which a chained execution ensues, effectively triggering steps 3-7 and propagating their backpressure upstream to the Receive Connector.

    • Notifications and Request Response actions usually require external interactions, but they typically do not trigger chained execution unless they interact with a separate flow. As a result, only the backpressure from Send Connectors will be propagated to the Receive Connector.

    • Unless they are remote or distributed in nature, Cache Adapters typically do not backpressure — accessing the cache is an in-memory operation.

    • Both the plain Send Connector and the Request Reply Send Connector provide a buffer for messages being sent in parallel. Once the buffer is full, it will slow down and then start dropping messages.

    • Both types of Send Connector support configurable retries and timeouts, which will be included in the backpressure slowdowns.
